600ah VRLA Sealed Lead Acid Replacement Battery 2V Maintenance Free

Minimum Order Quantity : 1PCS Price : $147/pcs
Brand Name: SHOTO Model Number: GFM-600

Detail Information

Model Number: GFM-600 Nominal Capacity: 600AH
Weight: 33.2kg Voltage: 2V
Size: 181*225*346/365mm Application: Telecom / Energy Storage / UPS
Color: Grey Type: Acid Lead Battery
Product Name: 2V 600AH Lead Acid Battery Terminal: M8
Highlight:

600ah lead acid replacement battery

,

2V lead acid replacement battery

,

VRLA 2v lead acid battery

Product Description

Product Description



Shoto GFM - 600 VRLA Maintenance - free Sealed Lead - acid AGM Battery for Telecom / Energy Storage / UPS





Normal Voltage
2V
Capacity
600Ah @ 10hr to 1.80V @ 25˚C(77˚F)
Weight
33.2 kg (73.19 lbs)

Dimensions
Length: 181 mm (7.13 in)
Width: 225 mm (8.86 in)
Height: 346 mm (13.62 in)
Total height: 365 mm (14.37 in)
Internal Resistance (full charged)
0.39 mΩ
Short- circuit current
5300A
Self Discharge @25˚C(77˚F)
Less than 3% after 30 days storage

Operating Temperature Range
Discharge: -40˚C ~ 50˚C(-40˚F ~ 122˚F)
Charge: -20˚C ~ 45˚C(-4˚F ~ 113˚F)
Storage: -20˚C ~ 40˚C(-4˚F ~ 104˚F)
Recommended Operating Temperature
15˚C ~ 25˚C (59˚F ~ 77˚F)
Recommended Charging Current
90A
Charging Voltage @25˚C(77˚F)
Float: 2.23 V/cell
Equalize: 2.35 V/cell
Terminal
M8

Capacity Affected by Temperature
106 % @ 40˚C
80 % @ 0˚C
60 % @ -20˚
Design life @25°C
15 years





Main Applications

1. Back-up power for communication and signal system
2. Back-up power for Electric power system&nuclear power station
3. Solar and wind power generation energy storage system
4. Back-up power for military&navigation
5. Back-up power for UPS&emergency lighting

Benefits

1. 15 years designed life
2. Adopt the TLS patent technology with reliable sealing
3. Unique design for monomer structure, complete range of models with wide choice
4. Mature product technology and stable operation

Technical Features

1. The plate is with the structure of big grid and block, and is made of special alloy through special process of quadric basic lead sulfate, which improves specific energy of the battery and prolongs the cycle service life

2. Positive grid is made of special multi alloy, which overcomes the shortcomings of early capacity loss. It has long service life under both float charge and cycle utilization.
3. Add special additives tothe positive and negative plate, improve the utilization of active material and charging acceptability

4. High-purity electrolyte and special additives Unique assembled maze seal structure of termi-nal (patented technology) ensures the safety and reliability of seal.
