10hr Rate 12V 80Ah Lead Acid Battery Renewable Energy Storage Battery For Telecom Site

Name: 10hr Rate 12V 80Ah Lead Acid Battery Renewable Energy Storage Battery For Telecom Site
Brand: SHOTO
SKU: 6-FMX-80
Price: 1 USD
Availability: InStock
Rating: 4.9 (153 reviews)

Minimum Order Quantity :	1pcs

Brand Name:	SHOTO	Model Number:	6-FMX-80

Detail Information
Model Number:	6-FMX-80	Nominal Capacity:	80Ah
Weight:	27kg	Size:	395105270/270mm
Voltage:	12V	Application:	Telecom / Energy Storage / UPS
Product Name:	12V 80AH Lead Acid Battery	Capacity:	80Ah 10hr Rate
High Light:	10hr Rate 12V 80Ah Lead Acid Battery , Telecom Site 12V 80Ah Lead Acid Battery , 80Ah Renewable Energy Storage Battery

Product Description

Shoto 6 - FMX - 80 VRLA Maintenance - free Sealed Lead - acid AGM Battery for Telecom / Energy Storage / UPS

Normal Voltage		12V
Capacity		80Ah @ 10hr to 1.80V @ 25˚C(77˚F)
Weight		27 kg (59.52 lbs)
Dimensions		Length: 395 mm Width: 105 mm Height: 270 mm Total Height: 270mm
Internal Resistance (full charged)		5.2 mΩ
Short-circuit Current		1755 A
Self Discharge @25˚C(77˚F)		Less than 4% after 30 days storage
Operating Temperature Range		Discharge: -40˚C ～ 50˚C(-40˚F ～ 122˚F) Charge: -20˚C ～ 45˚C(-4˚F ～ 113˚F) Storage: -20˚C ～ 40˚C(-4˚F ～ 104˚F)
Recommended Operating Temperature		15˚C ～ 25˚C (59˚F ～ 77˚F)
Recommended Charging Current		16 A
Charging Voltage @25˚C(77˚F)		Float: 2.23 V/cell Cycle: 2.35 V/cell
Terminal		M6
Capacity Affected by Temperature		103 % @ 40˚C 85 % @ 0˚C 60 % @ -20˚
Design life @25°C		12 years

Main Applications

1. Telecom site
2. Outdoor base station
3. Floating operation site
4. UPS

Benefits

1. Front terminal design, easy access for faster installation and maintainence
2. Optimal energy density, save oor space
3. No leakage and no acid smog spray during the operation

Technical Features

1. Excellent capacity retention rate

2. Long life oat service design

3. Excellent over discharge recovery

4. capability

Specific Parameters

Constant Current Discharge Characteristics Unit: A (25ºC, 77ºF)

Constant Power Discharge Characteristics Unit: W/cell (25ºC, 77ºF)

Performance Curve
